Our Home Construction Packages



1

Budget Package

1999 per sqft

Design

  • SCHEME DRAWING : ALL FLOORS (2D)
  • ELEVATION DESIGN : (3D)

Project Management

  • Site Engineer : One Visit Per Day
  • Project Manager : Visit site Once in a Week
  • Android/IOS App : Access to APP for Site Status update.

Structure

  • Basement Height : Upto 2 feet
  • Steel : Any ISI Brand
  • AAC : For Partition walls. 8-Inch Thick Exterior Walls | 4 Inch Thick Inner Walls
  • Cement : Penna / Priya
  • M Sand : Blockwork & All Masonry Works
  • P Sand : Plastering Works
  • Concrete Grade : M20 (Manual Mix)
  • Ceiling Height : 10 Feet
  • Steel Reinforcement : As per Standard
  • Parapet Wall : 3 Feet Height | 4" Thick (Only for Floor with Headroom)

Bathroom & Plumbing

  • Wall Tiles : Upto 7' Height. Size 2'X1' Vitrified Tile. Upto ₹40/Sqft
  • Bath & CP Fittings : Cera | Upto ₹12000 Per Bathroom | Floor Mounted EWC, Wall Mounted Wash Basin, Pillar Tap, Health Faucet, Shower Set, 2-in-1 Wall Mixer
  • Plumbing Pipes & Fittings : Inner CPVC, Outer PVC. Brands: Any ISI Brand
  • Overhead Tank : 1000 litres Sintex | 3 Layered | UV Protected | White Colour

Flooring

  • Living, Dining, Bedrooms & Kitchen : 2'X2' | Vitrified Tiles Upto ₹45/Sqft. Anuj / Sparrow
  • Balcony & Utility : Size 1'X1' | Upto 35/Sqft
  • Staircase : Size 1'X1' Tile : Upto ₹35/sqft
  • Car Parking : 1'X1' Parking Tile | Upto ₹35/Sqft
  • Terrace Flooring : Screed Concreting with Waterproofing

Kitchen & Dining

  • Wall Tile : Vitrified Tile (2'X1') | Upto ₹45/Sqft
  • Sink Faucet : Upto ₹900 / No
  • Kitchen Sink : Stainless Steel single bowl Upto ₹2800
  • Dining : Wall Mounted Wash Basin
  • Kitchen Granite Top : Upto ₹90/Sqft

Door, Windows and Railing

  • Main Door : Malaysian Teak Door & Teak Frame | 32mm Thickness | 5"X3" Thick Frame | 7' Height 3.5 Feet Width
  • Room Doors : White Panel Door | Sal Wood Frame | 7'X3'
  • Bathroom Door : PVC Door | 7'X2.5'
  • Windows : Aluminium Sliding window | Max 4' X 4' | One Window Per Room | 5mm Clear Glass
  • Staircase Railing : MS Railing
  • Balcony Railing : MS Railing

Painting

  • Inner Wall Putty : 2 coats of Wall Putty | Any ISI Brand
  • Wall Painting : 1 coat of Primer | 2 coats of Tractor emulsion | Any ISI Brand
  • Ceiling Painting : 1 coat of Primer | 2 coats of Tractor emulsion | Any ISI Brand
  • Exterior Paint : 1 coat of Primer | 2 Coats of Ace | Any ISI Brand

Electrical

  • Wires – Essar
  • Switches – Fybros
  • Bedroom : 2 Switch Box(8-Module). One at Entrance and one at Bed-side
  • Bathroom : 1 Switch Box(Inner) 4-Module, 1 Switch Box(Outer) 3-Module. Point for Heater & Exhaust
  • Living Room : Upto 4 Switch Box (8 Module)
  • Dining : 1 Switch (8-Module)
  • Pooja : 1 Switch (3-Module)
  • Kitchen : 3 Switch Box (6 Module). Point for HOB, Chimney, RO
  • Utility : 1 Switch Box (4-Module)
  • AC Points : 1 for Each Bedroom.
  • Entrance : 1 Switch Box (6-Module)
  • Balconies : 1 Switch Box (3-Module)

What's Not Included

  • Compound Wall @ 425/Sqtft & Gate
  • Sump & Septic Tank @ 24/Litre
  • Lift, Lift Pit and Shaft
  • Electricity Connection
  • Building Plan Approval
  • Elevation Special Materials

2

Smart Package

2199 per sqft

Design

  • SCHEME DRAWING : ALL FLOORS (2D)
  • ELEVATION DESIGN : (3D)
  • HALF LAYOUT : ALL FLOORS (3D)
  • ELECTRICAL DRAWINGS : ALL FLOORS (2D)
  • PLUMBING DRAWING : ALL FLOORS (2D)
  • WORKING DRAWING : ALL FLOORS (2D)

Project Management

  • Site Engineer : Dedicated Full-Time Site Engineer
  • Project Manager : Visit site Twice in a Week
  • Android/IOS App : Daily Photo Upload. Project Status Monitoring
  • Architect : Support Till Design Completion

Structure

  • Basement Height : Upto 3 feet
  • Steel : Arun TMT / GBR or Equivalent
  • Chamber Bricks : For Partition walls. 9-Inch Thick Exterior Walls | 4 Inch Thick Inner Walls
  • Cement : Ramco / Dalmia
  • M Sand : Blockwork & All Masonry Works
  • P Sand : Plastering Works
  • Concrete Grade : M20 | RMC for Roof
  • Ceiling Height : 10 Feet
  • Steel Reinforcement : As per Standard
  • Parapet Wall : 3' Feet Height | 6" Thick (Only for Floor with Headroom)

Bathroom & Plumbing

  • Wall Tiles : Upto Ceiling (Full Height). Size 2'X2' Vitrified Tile. Upto ₹50/Sqft. 1 Colour for 2 Bathrooms
  • Bath & CP Fittings : Parryware | Upto ₹17000 Per Bathroom | Wall Mounted EWC, Wall Mounted Wash Basin, Pillar Tap, Health Faucet, Shower Set, 2-in-1 Wall Mixer.
  • Plumbing Pipes & Fittings : Inner CPVC, Outer PVC. Brands: Any ISI Brand
  • Overhead Tank : 2000 litres Sintex | 3 Layered | UV Protected | White Colour

Flooring

  • Living, Dining, Bedrooms & Kitchen : 4'X2' | Vitrified Tiles Upto ₹65/Sqft. 1 Model for Living, Dining and Kitchen. KAG / Sunheart or Equivalent
  • Balcony & Utility : Size 2'X2' | Upto 50/Sqft | Antiskid
  • Staircase : Full Body Tile : Upto ₹110/sqft
  • Car Parking : 1'X1' Heavy Duty Tile | Upto ₹50/Sqft
  • Terrace Flooring : Screed Concreting with Waterproofing

Kitchen & Dining

  • Wall Tile : Vitrified Tile (2'X2') | Upto ₹55/Sqft
  • Sink Faucet : Upto ₹2000 / No
  • Kitchen Sink : Stainless Steel sink with Drain Upto ₹4000
  • Dining : Wall Mounted Wash Basin
  • Kitchen Granite Top : Upto ₹140/Sqft

Door, Windows and Railing

  • Main Door : Malaysian Teak Door & Teak Frame - Readymade | 35mm Thickness | 5"X3" Thick Frame | 7' Height 3.5 Feet Width | Upto 22000/nos | 1 Nos only.
  • Room Doors : Flush Door| Sal Wood Frame | 7'X3'
  • Bathroom Door : WPC Door & Frame | 7'X2.5'
  • Windows : UPVC Sliding White | Max 5' X 5' | One Window Per Room | 5mm Clear Glass
  • Staircase Railing : SS 304 Grade Railing
  • Balcony Railing : SS 304 Grade Railing with 8mm Toughened Glass with Posts

Painting

  • Inner Wall Putty : 2 coats of Wall Putty | Nippon
  • Wall Painting : 1 coat of Primer | 2 coats of Breeze emulsion | Nippon
  • Ceiling Painting : 1 coat of Primer | 2 coats of Breeze emulsion | Nippon
  • Exterior Paint : 1 coat of Primer | 2 Coats of Sumo Xtra | Nippon
  • Elevation Putty : 2 Coat of Putty for Front Elevation | Nippon Exterior Putty

Electrical

  • Wires – Orbit (FRLS)
  • Switches – Legrand
  • Bedroom : 3 Switch Box(8-Module)
  • Bathroom : 1 Switch Box(Inner) 4-Module, 1 Switch Box(Outer) 3-Module. Point for Heater & Exhaust
  • Living Room : Upto 4 Switch Box (8 Module)
  • Dining : 1 Switch (8-Module)
  • Pooja : 1 Switch (3-Module)
  • Kitchen : 3 Switch Box (6 Module). Point for HOB, Chimney, RO
  • Utility : 1 Switch Box (4-Module)
  • AC Points : 1 for Each Bedroom. 1 for Living Room
  • Entrance : 1 Switch Box (6-Module)
  • Balconies : 1 Switch Box (3-Module)

What's Not Included

  • Compound Wall @ 425/Sqtft & Gate
  • Sump & Septic Tank @ 24/Litre
  • Lift, Lift Pit and Shaft
  • Electricity Connection
  • Building Plan Approval
  • Elevation Special Materials

3

Premium Package

2499 per sqft

Design

  • SCHEME DRAWING : ALL FLOORS (2D)
  • ELEVATION DESIGN : (3D)
  • HALF LAYOUT : ALL FLOORS (3D)
  • ELECTRICAL DRAWINGS : ALL FLOORS (2D)
  • PLUMBING DRAWING : ALL FLOORS (2D)
  • WORKING DRAWING : ALL FLOORS (2D)
  • SOIL TEST REPORT
  • STRUCTURAL DRAWINGS
  • FURNITURE LAYOUT : ALL FLOORS (2D)
  • ELEVATION DETAIL DRAWING : (2D)

Project Management

  • Site Engineer : Dedicated Full-Time Site Engineer
  • Project Manager : Daily Site Visit
  • Android/IOS App : Daily Photo Upload. Project Status Monitoring.
  • Architect : Dedicated Architect through-out the Project. Stage wise Site Visit. Material Selection Support.

Structure

  • Basement Height : Upto 3.5 feet
  • Steel : ARS or Equivalent
  • Wire-Cut Bricks : For Partition walls. 9-Inch Thick Exterior Walls | 4 Inch Thick Inner Walls
  • Cement : Ramco / Dalmia
  • M Sand : Blockwork & All Masonry Works
  • River Sand : Plastering Works
  • Concrete Grade : M20 | RMC for Roof
  • Ceiling Height : 10 Feet (FFL to FFL)
  • Steel Reinforcement : As per tri spire designs Structural Detailing.
  • Parapet Wall : 3.5' Feet Height | 6" Thick
  • RCC Lift Pit : Included (If Required)
  • Lift Pit & Shaft : Included (If Required)

Bathroom & Plumbing

  • Wall Tiles : Upto Ceiling (Full Height). 4'X2' Digital Vitrified Tile. Upto ₹85/Sqft
  • Bath & CP Fittings : Jaquar | Upto ₹22000 Per Bathroom | Wall Mounted EWC, Wall Mounted Wash Basin, Pillar Tap, Health Faucet, Shower Set, Concealed Wall Mixer.
  • Plumbing Pipes & Fittings : Inner CPVC, Outer PVC. Brands: Ashirwad / Finolex
  • Overhead Tank : 3000 litres Sintex | 5 Layered | UV Protected | White Colour. With Sensor.
  • Solar Heater Plumbing Lines : Included (If Required)

Flooring

  • Living, Dining, Bedrooms & Kitchen : 4'X2' | Tiles Upto ₹80/Sqft. Somany / Kajaria / KAG / Sunheart
  • Balcony & Utility : Size 2'X2' | Upto 60/Sqft
  • Staircase : Granite Upto ₹160/sqft
  • Car Parking : 2'X2' Heavy Stone| Upto ₹80/Sqft
  • Terrace Flooring : White Cooling Tile Size 1'X1' | Anuj | with Waterproofing

Kitchen & Dining

  • Wall Tile : Vitrified Tile (4'X2') | Upto ₹65/Sqft
  • Sink Faucet : Designer Brand | Upto ₹3500 /nos
  • Kitchen Sink : Quartz Sink with Drain Upto ₹5000
  • Dining : Wash Basin with Granite Counter
  • Kitchen Granite Top : Upto ₹160/Sqft

Door, Windows and Railing

  • Main Door : Ghana Teak Door & Teak Frame | 35mm Thickness | 5"X3" Thick Frame | 8' Height 4 Feet Width.
  • Room Doors : Flush Door with Laminate | Ghana Wood Frame | 7'X3'
  • Bathroom Door : WPC Door & Frame | 7'X2.5'
  • Windows : UPVC Sliding White - No Restriction on Size and Quantity | 5mm Clear Glass
  • Staircase Railing : SS 304 Grade Railing
  • Balcony Railing : 10mm Full Toughened Glass with 304 Grade Railing.

Painting

  • Inner Wall Putty : 2 coats of Wall Putty | Birla
  • Wall Painting : 1 coat of Primer | 2 coats of Pro Matex Gold Emulsion | Nippon
  • Ceiling Painting : 1 coat of Primer | 2 coats of Pro Matex Gold Emulsion | Nippon
  • Exterior Paint : 1 coat of Primer | 2 Coats of Weather bond PRO from Nippon
  • Elevation Putty : 2 Coat of Putty for Two sides of Elevation | Birla Wallseal Waterproof

Electrical

  • Wires – Finolex / Havells (FRLS)
  • Switches – GM
  • No Restriction on Number of Points. Except for Lifts, DG, Curtain Motors, Swimming Pool, Ro Plant, Pressure Pump, Intercom, Surveillance System, Exterior Light Points, Gate Automation, lightening arrester, Hybrid Solar Heater, Water Fountain, HVAC Systems.
  • Electricity Panel Board - Single Service with RLCB - Exterior Grade

What's Not Included

  • Compound Wall @ 425/Sqtft & Gate
  • Sump & Septic Tank @ 24/Litre
  • Lift
  • Electricity Connection
  • Building Plan Approval
  • Elevation Special Materials

4

Ultra Luxury

2999 per sqft

Design

  • SCHEME DRAWING : ALL FLOORS (2D)
  • ELEVATION DESIGN : (3D)
  • HALF LAYOUT : ALL FLOORS (3D)
  • ELECTRICAL DRAWINGS : ALL FLOORS (2D)
  • PLUMBING DRAWING : ALL FLOORS (2D)
  • WORKING DRAWING : ALL FLOORS (2D)
  • SOIL TEST REPORT
  • STRUCTURAL DRAWINGS
  • FURNITURE LAYOUT : ALL FLOORS (2D)
  • ELEVATION DETAIL DRAWING : (2D)
  • SITE ASSESSMENT & SITE PLAN
  • INTERIOR VIEWS : ALL FLOORS (3D)
  • INTERIOR DETAILING : ALL ROOMS (2D)
  • INTERIOR 3D WALK-THROUGH
  • APPROVAL DRAWING
  • LANDSCAPING ARCHITECTURAL DESIGNS

Project Management

  • Site Engineer : Dedicated Full-Time Site Engineer
  • Project Manager : Daily Site Visit
  • Android/IOS App : Daily Photo Upload. Project Status Monitoring
  • Architect : Dedicated Architect. Frequent Site Visit. Material & Brand Selection Support including Interiors and Home Decor.

Structure

  • Basement Height : Upto 5 feet
  • Steel : TATA Steel
  • Wire-Cut Bricks : For Partition walls. 9-Inch Thick Exterior Walls | 4 Inch Thick Inner Walls
  • Cement : Ramco / Dalmia / Coramandel
  • River Sand : Blockwork & All Masonry Works
  • River Sand : Plastering Works
  • Concrete Grade : M25 | RMC for Roof
  • Ceiling Height : 11 Feet (FFL to FFL)
  • Steel Reinforcement : 1.5times Strength all as per tri spire designs Structural Drawings and Detailing by tri spire designs Structural Engineer.
  • Parapet Wall : 3.5' Feet Height | 6" Thick (Or) Toughened Glass Railing if Required.
  • RCC Lift Pit : Included (If Required)
  • RCC Concrete Slab for Base
  • Lift Pit & Shaft : Included (If Required)

Bathroom & Plumbing

  • Wall Tiles : Upto Ceiling (Full Height). 4'X2' Vitrified Tile. Upto ₹120/Sqft
  • Bath & CP Fittings : Kohler | Upto ₹60000 Per Bathroom | Concealed EWC, Counter Top Wash Basin, Marble Counter Slab, Pillar Tap, Health Faucet, Shower Set, Concealed Wall Mixer.
  • Plumbing Pipes & Fittings : Inner CPVC, Outer PVC. HDPE flexible pipe. Brands: Ashirwad / Finolex / Jindal
  • RCC Overhead Tank : Upto 6000 litres with Waterproofing.
  • Solar Heater Plumbing Lines : Included (If Required)

Flooring

  • Living, Dining, Bedrooms & Kitchen : 6'X6' | Quarts Tiles Upto ₹200/Sqft
  • Balcony & Utility : Size 2'X2' | Upto 60/Sqft
  • Staircase : Marble Upto ₹350/sqft
  • Car Parking : Granite| Upto ₹120/Sqft
  • Terrace Flooring : 2'X2' Exterior Grade Vitrified Tile. (Any Grade) | with Waterproofing

Kitchen & Dining

  • Wall Tile : Vitrified Designer Tile (4'X2') | Upto ₹125/Sqft
  • Sink Faucet : Floor Mounter Pull-Out | Upto ₹8000 / No
  • Kitchen Sink : Multifunction Sink Upto ₹15000
  • Dining : Premium Designer Collection Wash Basin with Marble Counter and Designer Tap.
  • Kitchen Top : Quarts Stone Upto ₹350/Sqft

Door, Windows and Railing

  • Main Door : Designer Wood Door of Height upto 8Feet X 5Feet (or) Security Steel Door of Size (8'X4.5') Pure Stainless Steel with Digital Lock.
  • Room Doors : Flush Door with Laminate | Ghana Wood Frame | 8'X3.5'
  • Water Proof Flush Door with Designer Laminates | 8'X3'
  • Windows : Openable Type | UPVC Coloured | No Restriction on Size and Quantity | Toughened Glass
  • Staircase Railing : Toughened Glass with SS or Wood Railing or Aluminium
  • Balcony Railing : 10mm Full Toughened Glass with Aluminium Railing.

Painting

  • Inner Wall Putty : 2 coats of Wall Putty | Birla
  • Wall Painting : 1 coat of Primer | 2 coats of Royal Shyne | Asian
  • Ceiling Painting : 1 coat of Primer | 2 coats of Royal Shyne | Nippon
  • Exterior Paint : 1 coat of Primer | 2 Coats of Apex Ultima ProteK | Asian
  • Elevation Putty : 2 Coat of Putty for All sides of Elevation | Birla Wallseal Waterproofing

Electrical

  • Wires – Finolex / Havells (FRLS)
  • Switches – Touch Switches with Glass Plates.
  • No Restriction on Number of Points. Required power points will be provided for Lifts, DG, Curtain Motors, Swimming Pool, Ro Plant, Pressure Pump, Intercom, Surveillance System, Exterior Light Points, Gate Automation, lightening arrester, Hybrid Solar Heater, Water Fountain, HVAC Systems.
  • Electricity Panel Board - Upto 2 Service Connection with RLCB Exterior Grade

What's Not Included

  • Compound Wall @ 425/Sqtft & Gate
  • Sump & Septic Tank @ 24/Litre
  • Lift
  • Electricity Connection
  • Building Plan Approval
  • Elevation Special Materials

* Note : Minimum overall built-up area should be 2000 sqft.



Request a Free Quote with Material & Brand Details





Work Area Unit Rate Cost
Enter required Built up Area for Ground Floor sqft Rs.1999 Rs. 0
Enter required Built up Area for First Floor sqft Rs.1999 Rs. 0
Enter required Built up Area for Second Floor sqft Rs.1999 Rs. 0
Enter required Built up Area for Third Floor sqft Rs.1999 Rs. 0
Enter required Built up Area for Fourth Floor sqft Rs.1999 Rs. 0
Enter required Built up Area for Fifth Floor sqft Rs.1999 Rs. 0
Size of RCC Water Sump (A 4 member family will require 9000 liter capacity) ltr Rs.24 Rs. 0
Size of Septic Tank ltr Rs.24 Rs. 0
Plain Compound Wall sqft Rs.425 Rs. 0
Total Construction Cost Rs. 0

Home Construction Cost Calculator (2025) Chennai

You can arrive your Construction estimate here

1. How many Floors are you Planning to Build?

2. Select your preferred Package

3. Enter the required size of Each Floor in sqft

Ground Floor
First Floor
Second Floor
Third Floor
Fourth Floor
Fifth Floor

4. How many liters of Sump do you require?

Total Estimation   Rs.0/-

Check Your free Quote







Home Construction Specialists We Build. You Relax


STUCCOO Designs is a leading architecture firm in Chennai, renowned for its expertise in architecture, construction, and interior design. We offer comprehensive turnkey construction solutions, helping you bring your dream home to life—from concept to completion.
If you're searching for the best architects in Chennai to design and build your home, look no further. STUCCOO stands out as one of the most trusted and experienced building contractors in Chennai, committed to delivering quality, innovation, and excellence in every project.

10+ Years Experience service

Completed Site Showcase

Real Site Images

Beach House by tri spire designs
Best Architects in Chennai
Architects in Chennai
Residential Architects in Chennai
Construction Company in Chennai
Residential Construction Company in Chennai
Best Residential Architect in Chennai
Top Construction Companies in Chennai

Why Stuccoo designs ?

10+
Years of
Experience
250+
Completed
Projects
75+
Ongoing
Projects
50+
Permanent
Staff Members
1500+
Construction
Workers
1
Offices
in 5 Cities
5
Years
Warranty
395
Quality
Checks





Bank Loan & Building Approval Support

Dedicated Full Time
Site Engineer

On-Time
Handover

One Stop Solution
Design + Construction + Interior



How We Work

We Make Building Your Home Easy to Understand and Easy to Love
  • We Make Building Your Home Easy to Understand and Easy to Love
  • One of our architects will connect with you to better understand your project
  • Our senior architect and project team will visit your site to assess the space
  • We’ll share a complete estimate along with specifications and payment details
  • Confirm your project by paying ₹2.5 lakhs and signing the construction contract
  • Design development and approval process begins
  • Work begins—just sit back and watch your dream home take shape
tri spire designs
tri spire designs Architects
Construction Company
Architecture Firm
Home Construction
Residential Construction
Architectural Designs
//

Complete Home Building Services

Architectural Designs

Architectural
Designs

Residential Construction

Residential
Construction

Interior Designs

Interior
Designs





Join us on the journey to create your perfect home.



🏠🎨 Let Stuccoo transform your dream home into reality with our top-notch architecture and construction expertise.

With over a decade of experience, we proudly stand as India’s leading firm for residential construction and interior design. 🏗️👷‍♀️👷‍♂️

Start your home-building journey with us today!

#stuccoo #DreamHome #ArchitectureAndDesign #HomeConstruction #InteriorDesign 🌇🏙️


tri spire designs _architects

Stuccoo

115K followers
View Profile

POSTS REELS SAVED TAGGED

Enquire Now
